Our range FRAM K, 4 models to introduce
we offer our RK models with four different front dimensions, simple lines and minimalist design.
The different sizes of the pane - in combination with the simple operating elements
- putting the flames of the wood fire effectively in scene and becoming a highlight in every room situation
Wonderfully suitable for renovations and small, simple installations.
- Energy efficiency class: A+
- Energy nominal power: 8,0 kW
- Power range: 3.5-10,0 kW
- Thermal efficiency: 84,0 %
- Dust emission (13% O2): 14 mg/m3
- CO-Emission (at 13% O2): 0,09 %, 1085 mg/m3
- Fine dust: 40 mg/Nm3
- Delivery pressure at nominal output: 12 Pa
- Exhaust mass flow: 9,5 g/s
- Exhaust gas temperature: 165 °C
- Flue diameter: 150 mm
- Permitted fuels: wood, wood briquettes
- Firewood length up to max.: 50 cm
- Dimension (W / H / D): 760 / 520 / 471 mm
- Weight: 110 kg
- Ventilator power input: 38 kW
- Ventilator noise level: 38 dB
- Ventilator perfomance: 280 m3/h
- Glazing type: flat
- Door opening direction: hinged
- Material: steel, Termotec
- BImSchV Step 2: ✓
- External air supply: -
- Combustion chamber lining: ✓
- Ash pan: ✓
- Design glass (frameless): ✓
